The RR Race 430 4T is the four-stroke that puts engine power first. A mix of torque and power that transforms every acceleration into constant thrust, without sacrificing stability and precision.
Generous torque, endless traction and absolute stability: the RR Race 430 4T is made for those who love to push hard and tackle every trail with total confidence. Powerful but always controllable, it combines the thrust of a large 4-stroke with the balance and solidity typical of Beta’s DNA.
CHASSIS
FRAME
Molybdenum steel with double cradle split above
the exhaust port
WHEELBASE
1480 mm
MAX LENGHT
2180 mm
MAX WIDTH
830 mm
MAX HEIGHT
1275 mm
SEAT HEIGHT
950 mm
GROUND CLEARANCE
335 mm
FOOTREST HEIGHT
427 mm
DRY WEIGHT
107,5 kg (front 52,7 kg; rear 54,8 kg)
FUEL TANK CAPACITY
9,0 l
RESERVE
2,3 l
COOLING SYSTEM CAPACITY
1,4 l
FRONT SUSPENSION
Hydraulic usd fork with Ø 48 mm shaft
REAR SUSPENSION
Monoshock with progressive compound lever
SHOCK ABSORBER STROKE
130 mm
FRONT WHEEL TRAVEL
300 mm
REAR WHEEL TRAVEL
287 mm
FRONT BRAKE
Wave disc Ø260 mm and double-piston floating caliper
REAR BRAKE
Wave disc Ø240 mm and single-piston floating caliper
FRONT RIM
21 x 1,6 – 36 holes
REAR RIM
18 x 1,85 – 36 holes
FRONT TYRE
90/90 – 21
REAR RYRE
140/80 -18
ENGINE
TYPE
Single-cylinder, 4-stroke, liquid-cooled
BORE
95 mm
SROKE
60,8 mm
DISPLACEMENT
430,9 cc
COMPRESSION RATIO
12,33:1
VALVE TRAIN
Dohc finger follower / 4 titanium valve, intake titanium,
exhaust steel
STARTER
Electric starter
acg
Kokusan
spark plug
NGK LKAR 8A-9
lubrication
2 oil pumps
fuel system
Elldor dual electronic injection
throttle body
Ø 42 mm – Synerject
clutch
Wet multi-disc clutch
primary drive
Z.23/76
transmission
6 gears
finl transmission
Chain
eNGINE OIL
SAE 10W/50 0,8 l. + SAE 10W/40 0,8 l.
CONSUMPTION l/100km
3,8
CONSUMPTION Co2 [g/km]
91
