The EVO 80 Junior is the ultimate training bike, the perfect link from electric mini trials to competition bikes. It is tailor-made for young riders taking their first steps in trials. Every component, from the frame to the engine, is sized for their ergonomics, offering maximum confidence and safe, step-by-step learning.
From the first corner to the first obstacle overcome. The EVO 80 Junior is the ultimate tool for learning the basics of trial riding the right way. Every detail is designed to instil confidence and allow the rider to grow technically, with a bike that is a true companion for adventures, safe and fun.
chassis
Frame
Steel
Wheelbase
1210 mm
Max length
1850 mm
Max width
720 mm
Max height
1070 mm
Seat height
620 mm
Ground clearance
300 mm
Footrest height
330 mm
Fuel tank capacity
2,5 l
Reserve
0,5 l
Cooling circuit capacity
600 cc
Front suspension
Hydraulic fork with ø33 mm shaft
Rear suspension
Monoshock with adjustable spring preload
Shock stroke
34 mm
Front wheel travel
160 mm
Rear wheel travel
146 mm
Front brake
Disc ø175 mm with 2 opposed pistons
Rear brake
Disc ø150 mm with 2 opposed pistons
Front rim
19 x 1,4 – 36 holes
Rear rim
17 x 1,6 – 36 holes
Front tire
2,50 – 19
Rear tire
3,50 – 17
engine
Type
Single cylinder, 2-stroke, liquid-cooled, reed induction into the crankcase
Bore
48 mm
Stroke
44 mm
Total displacement
79,6 cc
Compression ratio
14,7:1
Ignition
Hidria electronic
Lubrication
Mix with fuel 1,5 % (synthetic oil)
Spark plug
Champion RN3C
Fuel system
Carburetor
Carburetor
Dell’Orto PHBG 21
Clutch
Wet multi-disc clutch
Primary drive
Z. 20/77
Gearbox
6-speed
Final drive
Z. 11/54
Engine oil
SAE 20W/30 (300cc)
